CV42-CS
Valve Specification
- Body Material: Carbon Steel (ASTM A216 Gr. WCB)
- End Connection:
- ASME Rating: Class 150
- Size Range: 2 in ~ 24 in
Pressure Rating
- Carbon Steel - ASTM A216 Gr. WCB - Class 150 2 ~ 24 - WOG (Non-shock): 285 PSI @ 100 °F
General Information
Pressure-Temperature Chart
Pressure Drop Calculator
List Price View
Part Numbers
General Information
-
Product Features
- Cost Efficient Design
- Minimal Head Loss
- Quick Closure To Reduce Water Hammer
- Designed For Long Service Life
- Fugitive Emission Design
- Resilient and Metal Seats
Pressure-Temperature Chart
Pressure Drop Calculator
Please select a valid form
List Price View
| Series | Model | Size | Part Code | Body Material | End Connections | ASME Class | List Standard | List Mesh |
|---|---|---|---|---|---|---|---|---|
| CV42-CS | CV42-CSB | 2 | CV42CSB0200 | Carbon Steel | Wafer | Class 150 | 573.00 | |
| CV42-CS | CV42-CSB | 2 | CV42CSB0250 | Carbon Steel | Wafer | Class 150 | 667.00 | |
| CV42-CS | CV42-CSB | 3 | CV42CSB0300 | Carbon Steel | Wafer | Class 150 | 840.00 | |
| CV42-CS | CV42-CSB | 4 | CV42CSB0400 | Carbon Steel | Wafer | Class 150 | 1,064.00 | |
| CV42-CS | CV42-CSB | 5 | CV42CSB0500 | Carbon Steel | Wafer | Class 150 | 1,645.00 | |
| CV42-CS | CV42-CSB | 6 | CV42CSB0600 | Carbon Steel | Wafer | Class 150 | 2,188.00 | |
| CV42-CS | CV42-CSB | 8 | CV42CSB0800 | Carbon Steel | Wafer | Class 150 | 4,108.00 | |
| CV42-CS | CV42-CSB | 10 | CV42CSB1000 | Carbon Steel | Wafer | Class 150 | 6,095.00 | |
| CV42-CS | CV42-CSB | 12 | CV42CSB1200 | Carbon Steel | Wafer | Class 150 | 8,049.00 | |
| CV42-CS | CV42-CSB | 14 | CV42CSB1400 | Carbon Steel | Wafer | Class 150 | 11,481.00 | |
| CV42-CS | CV42-CSB | 16 | CV42CSB1600 | Carbon Steel | Wafer | Class 150 | 14,231.00 | |
| CV42-CS | CV42-CSB | 18 | CV42CSB1800 | Carbon Steel | Wafer | Class 150 | 17,190.00 | |
| CV42-CS | CV42-CSB | 20 | CV42CSB2000 | Carbon Steel | Wafer | Class 150 | 22,734.00 | |
| CV42-CS | CV42-CSB | 24 | CV42CSB2400 | Carbon Steel | Wafer | Class 150 | 33,646.00 | |
| CV42-CS | CV42-CSB | 30 | CV42CSB3000 | Carbon Steel | Wafer | Class 150 | 71,720.00 | |
| CV42-CS | CV42-CSB | 36 | CV42CSB3600 | Carbon Steel | Wafer | Class 150 | 108,103.00 | |
| CV42-CS | CV42-CSM | 2 | CV42CSM0200 | Carbon Steel | Wafer | Class 150 | 563.00 | |
| CV42-CS | CV42-CSM | 2 | CV42CSM0250 | Carbon Steel | Wafer | Class 150 | 656.00 | |
| CV42-CS | CV42-CSM | 3 | CV42CSM0300 | Carbon Steel | Wafer | Class 150 | 827.00 | |
| CV42-CS | CV42-CSM | 4 | CV42CSM0400 | Carbon Steel | Wafer | Class 150 | 1,046.00 | |
| CV42-CS | CV42-CSM | 5 | CV42CSM0500 | Carbon Steel | Wafer | Class 150 | 1,617.00 | |
| CV42-CS | CV42-CSM | 6 | CV42CSM0600 | Carbon Steel | Wafer | Class 150 | 2,151.00 | |
| CV42-CS | CV42-CSM | 8 | CV42CSM0800 | Carbon Steel | Wafer | Class 150 | 4,471.00 | |
| CV42-CS | CV42-CSM | 10 | CV42CSM1000 | Carbon Steel | Wafer | Class 150 | 6,480.00 | |
| CV42-CS | CV42-CSM | 12 | CV42CSM1200 | Carbon Steel | Wafer | Class 150 | 8,192.00 | |
| CV42-CS | CV42-CSM | 14 | CV42CSM1400 | Carbon Steel | Wafer | Class 150 | 11,522.00 | |
| CV42-CS | CV42-CSM | 16 | CV42CSM1600 | Carbon Steel | Wafer | Class 150 | 12,733.00 | |
| CV42-CS | CV42-CSM | 18 | CV42CSM1800 | Carbon Steel | Wafer | Class 150 | 15,575.00 | |
| CV42-CS | CV42-CSM | 20 | CV42CSM2000 | Carbon Steel | Wafer | Class 150 | 19,452.00 | |
| CV42-CS | CV42-CSM | 24 | CV42CSM2400 | Carbon Steel | Wafer | Class 150 | 29,099.00 | |
| CV42-CS | CV42-CSM | 30 | CV42CSM3000 | Carbon Steel | Wafer | Class 150 | 59,656.00 | |
| CV42-CS | CV42-CSM | 36 | CV42CSM3600 | Carbon Steel | Wafer | Class 150 | 83,663.00 | |
| CV42-CS | CV42-CSM | 42 | CV42CSM4200 | Carbon Steel | Wafer | Class 150 | 120,972.00 | |
| CV42-CS | CV42-CSM | 48 | CV42CSM4800 | Carbon Steel | Wafer | Class 150 | 158,056.00 | |
| CV42-CS | CV42-CSV | 2 | CV42CSV0200 | Carbon Steel | Wafer | Class 150 | 573.00 | |
| CV42-CS | CV42-CSV | 2 | CV42CSV0250 | Carbon Steel | Wafer | Class 150 | 667.00 | |
| CV42-CS | CV42-CSV | 3 | CV42CSV0300 | Carbon Steel | Wafer | Class 150 | 840.00 | |
| CV42-CS | CV42-CSV | 4 | CV42CSV0400 | Carbon Steel | Wafer | Class 150 | 1,064.00 | |
| CV42-CS | CV42-CSV | 5 | CV42CSV0500 | Carbon Steel | Wafer | Class 150 | 1,645.00 | |
| CV42-CS | CV42-CSV | 6 | CV42CSV0600 | Carbon Steel | Wafer | Class 150 | 2,188.00 | |
| CV42-CS | CV42-CSV | 8 | CV42CSV0800 | Carbon Steel | Wafer | Class 150 | 4,520.00 | |
| CV42-CS | CV42-CSV | 10 | CV42CSV1000 | Carbon Steel | Wafer | Class 150 | 6,849.00 | |
| CV42-CS | CV42-CSV | 12 | CV42CSV1200 | Carbon Steel | Wafer | Class 150 | 8,625.00 | |
| CV42-CS | CV42-CSV | 14 | CV42CSV1400 | Carbon Steel | Wafer | Class 150 | 12,170.00 | |
| CV42-CS | CV42-CSV | 16 | CV42CSV1600 | Carbon Steel | Wafer | Class 150 | 15,969.00 | |
| CV42-CS | CV42-CSV | 18 | CV42CSV1800 | Carbon Steel | Wafer | Class 150 | 19,496.00 | |
| CV42-CS | CV42-CSV | 20 | CV42CSV2000 | Carbon Steel | Wafer | Class 150 | 25,403.00 | |
| CV42-CS | CV42-CSV | 24 | CV42CSV2400 | Carbon Steel | Wafer | Class 150 | 38,065.00 | |
| Size | Part Code | Body Material | End Connections |
Part Numbers
Available Soon - Check Back Often
