Name: DS696-AB
SKU: DS696-AB
Availability: InStock

DS696-AB

Duplex Strainer Specification

Body Material: Aluminum Bronze (B148)
End Connection: Flanged - RF Ends
ASME Rating: Class 150
Size Range: 1 in ~ 4 in

Pressure Rating

Aluminum Bronze - ASTM B148 Gr. 9D - Class 150

Documents

General Information

Pressure-Temperature Chart

Pressure Drop Calculator

List Price View

Part Number

General Information

Product Features

ASTM B148 Body Material
Dual-Ball Diverter Design
Easy to Operate
Reduced "In-line" Maintenance

Pressure-Temperature Chart

Pressure Drop Calculator

Step 1: Select Strainer Size

Strainer Model (Read Only)

Step 2: Enter Flow Rate

gpm

Estimated Flow Coefficient (Read Only)

Step 3: Select Screen Type

Estimated Correction Factor (Read Only)

Result: Estimated Pressure Drop (Read Only)

psi

Notice - Acceptable Pressure Loss

Caution - Excessive Pressure Loss

Danger - Critical Pressure Loss

These values are theoretical and are provided for estimation purposes only.
Actual results will vary depending on application conditions.

If you are human, leave this field blank.

List Price View

Series	Model	Size	Part Code	Body Material	End Connections	ASME Class	List Standard	List Mesh
DS696-AB	DS696-AB	1	DS696AB0100	Aluminum Bronze	Flanged	Class 150	10,121.00	10,990.00
DS696-AB	DS696-AB	1	DS696AB0125	Aluminum Bronze	Flanged	Class 150	14,235.00	15,455.00
DS696-AB	DS696-AB	1	DS696AB0150	Aluminum Bronze	Flanged	Class 150	14,235.00	15,455.00
DS696-AB	DS696-AB	2	DS696AB0200	Aluminum Bronze	Flanged	Class 150	19,505.00	21,177.00
DS696-AB	DS696-AB	2	DS696AB0250	Aluminum Bronze	Flanged	Class 150	30,839.00	33,481.00
DS696-AB	DS696-AB	3	DS696AB0300	Aluminum Bronze	Flanged	Class 150	36,373.00	39,490.00
DS696-AB	DS696-AB	4	DS696AB0400	Aluminum Bronze	Flanged	Class 150	44,358.00	48,158.00
		Size	Part Code	Body Material	End Connections

Pricing applies exclusively to Stocked Mesh/Perforation Sizes of material Type 304 SS .
Stocked Mesh Lined Sizes include: "10-20-30-40-60-80-100."
Stocked Perforation Sizes include: "1/32-3/64-1/16-1/8-5/32-1/4."

Part Number

Available Soon - Check Back Often
