YS82-SS

Y Strainer Specification

Body Material: Stainless Steel (A351 Gr. CF8M)
End Connection: Socket Weld Ends
ASME Rating: Class 600
Size Range: 1/4 in ~ 2 in

Pressure Rating

Stainless Steel - ASTM A351 Gr. CF8M - Class 600

Documents

General Information

Pressure-Temperature Chart

Pressure Drop Calculator

List Price View

Part Number

General Information

Product Features

Cap Cover (1/4 ~ 2)
Rugged - High Quality Design
Large Straining Capacity
Precision Machined Seats
Self Cleaning Capability
Epoxy Painted

Pressure-Temperature Chart

Pressure Drop Calculator

Step 1: Select Strainer Size

Strainer Model (Read Only)

Step 2: Enter Flow Rate

gpm

Estimated Flow Coefficient (Read Only)

Step 3: Select Screen Type

Estimated Correction Factor (Read Only)

Result: Estimated Pressure Drop (Read Only)

psi

Notice - Acceptable Pressure Loss

Caution - Excessive Pressure Loss

Danger - Critical Pressure Loss

These values are theoretical and are provided for estimation purposes only.
Actual results will vary depending on application conditions.

If you are human, leave this field blank.

List Price View

Series	Model	Size	Part Code	Body Material	End Connections	ASME Class	List Standard	List Mesh
YS82-SS	YS82-SS	0	YS82S0025	Stainless Steel	Socket	Class 600	299.00	325.00
YS82-SS	YS82-SS	0	YS82S0038	Stainless Steel	Socket	Class 600	299.00	325.00
YS82-SS	YS82-SS	0	YS82S0050	Stainless Steel	Socket	Class 600	314.00	340.00
YS82-SS	YS82-SS	0	YS82S0075	Stainless Steel	Socket	Class 600	381.00	411.00
YS82-SS	YS82-SS	1	YS82S0100	Stainless Steel	Socket	Class 600	566.00	609.00
YS82-SS	YS82-SS	1	YS82S0125	Stainless Steel	Socket	Class 600	685.00	738.00
YS82-SS	YS82-SS	1	YS82S0150	Stainless Steel	Socket	Class 600	1,023.00	1,115.00
YS82-SS	YS82-SS	2	YS82S0200	Stainless Steel	Socket	Class 600	1,523.00	1,638.00
		Size	Part Code	Body Material	End Connections

Pricing applies exclusively to Stocked Mesh/Perforation Sizes of material Type 304 SS .
Stocked Mesh Lined Sizes include: "10-20-30-40-60-80-100."
Stocked Perforation Sizes include: "1/32-3/64-1/16-1/8-5/32-1/4."

Part Number

Available Soon - Check Back Often
